Plans of Bungalow L105

Family house L105

intro     floor plan    info
Modern 3 bedroom bungalow of L shaped floor plan
The rooms are oriented to the street and the living room with the patio is oriented to the garden, this way we have completely avoided the windows on the side facades. Thanks to this solution the house is suitable for sites  with a minimum width of 14.7 m (clear distance of 2.0 m on both sides).
Bungalow l105 - View from street
Bungalow l105 - View from garden
Bungalow l105 - Interior
Bungalow l105 - Interior
Layout
Entrance to the house is sheltered by the roof overhang. In the entry hall, there is enough space for two built-in wardrobes. The kitchen is connected with dining room and living room. The living room is facing the terrace that is accessible through sliding doors. The l-shaped volume of the house creates privacy on the terrace. The house is suitable for plots with a minimum width of 14.7 meters (while keeping clear distance of 2m on both sides). There is an option to annex a garage to the house (the width of the house then increases to 18.6m.


Technical information

Walls are designed from aerated concrete blocks, which can be easily switched for bricks during construction, if desired. The roof is a truss roof and we designed a storage space for seasonal items there. There is floor heating designed in the whole house.

Architectural features
The house is designed as a combination of white plaster in combination with wood cladding. The roofing is concrete of grey color, the windows are plastic of anthracite color.

Floor plan

If you would like to modify the floor plan, please contact us. Approximate prices of house modifications can be found in our price list of additional services.Mirrored version of house plan is included in price (optional).
Bungalow L105 - Floor plan
Bungalow L105 - Floor plan - Mirrored
Mirrored floor plan is displayed
Original floor plan is displayed

Parameters

Floor area
103.48 m2
Built-up area
123.53 m2
Roof height
4 650 mm
Roof slope
16°
Number of bedrooms
3
Exterior dimensions
10.63 m x 15.0 m
Material costs
54 000 €
Turnkey construction costs
98 800 €
Architectural study in pdf
80 €  (only digital files)
Architectural study in dwg
250 €  (only digital files)
Construction drawings
1 100 €
Non-binding pre-order

Download more information

For each project you bought from us, we offer site plan drawing as well as the projects of all necessary connections for a discounted price. For further information, please refer to our price list of additional services
More information about this house
House plan L105 - More information
Download floor plan of this house
House L105 - Floor plan in pdf

Elevations

Bungalow L105 - Right elevation
Bungalow L105 - Front elevation
Bungalow L105 - Left elevation
Bungalow L105 - Back elevation
